Screw-In-Cartridge Valves - Relief Cartridge Valves

Direct Acting, Pilot Stage SRV2

General Description

1. Maximum operating pressure = 5000 psi
2. Typical response time 2 ms.
3. Maximum leakage less than 0.4 cc/min.
4. Back pressure on the tank port (port 2) is directly additive at a 1:1 ratio to the valve setting
